3108NL-04W-B19-P50

Part Number	3108NL-04W-B19-P50
Description	FAN AXIAL 80X20MM 12VDC WIRE
Category	Fans
Manufacturer	NMB Technologies Corp.
In Stock	18296
Datasheet	Download

Category: Fans

Description

Description

Manufacturer	NMB Technologies Corp.
Lead / RoHS Status	Lead free / RoHS Compliant
Width	20.00mm
Weight	0.187 lb (84.82g)
Voltage Range	6 ~ 13.8VDC
Voltage – Rated	12VDC
Termination	3 Wire Leads
Static Pressure	0.084 in H2O (20.9 Pa)
Size / Dimension	Square – 80mm L x 80mm H
Series	3108NL
RPM	2350 RPM
Power (Watts)	1.08W
Other Names	3108NL04WB19P50 3108NL04WB19P50-ND
Operating Temperature	14 ~ 158°F (-10 ~ 70°C)
Noise	26.0 dB
Material – Frame	Plastic
Material – Blade	Plastic
Features	Speed Sensor (Tach)
Fan Type	Tubeaxial
Current Rating	0.090A
Bearing Type	Ball
Approvals	CE, CSA, UL, VDE
Air Flow	26.5 CFM (0.742m³/min)
