CPS19-LA00A10-SNCCWTNF-AI0CRVAR-W1075-S

Part Number

Description

Manufacturer	Schurter
Lead / RoHS Status	Lead free / RoHS Compliant
Voltage Rating – DC	60V
Voltage Rating – AC	42V
Type	Capacitive, Illuminated
Termination Style	Wire Leads
Switch Function	Off-On
Series	CPS
Panel Cutout Dimensions	Circular – 19.10mm Dia
Packaging	Bulk
Operating Temperature	-40°C ~ 60°C
Mounting Type	Panel Mount, Front
Moisture Sensitivity Level	1 (Unlimited)
Ingress Protection	IP67 – Dust Tight, Waterproof
Illumination Voltage	5 ~ 28 VDC
Illumination Type, Color	LED, Cyan/Red
Features	Ceramic Actuator, Light Bulb Symbol
Detailed Description	Pushbutton Switch SPST Capacitive, Illuminated Panel Mount, Front
Current Rating	100mA (AC/DC)
Color – Actuator/Cap	Clear (White Filter/Diffuser)
Circuit	SPST
Actuator Type	Round, Button, Flush
