CPS22-NC00A10-SNCCWTWF-AI0WBVAR-W1060-S

Part Number

Description

Manufacturer	Schurter
Lead / RoHS Status	Lead free / RoHS Compliant
Voltage Rating – DC	60V
Voltage Rating – AC	42V
Type	Capacitive, Illuminated
Termination Style	Wire Leads
Switch Function	On-Mom
Series	CPS
Panel Cutout Dimensions	Circular – 22.10mm Dia
Packaging	Bulk
Operating Temperature	-40°C ~ 60°C
Mounting Type	Panel Mount, Front
Ingress Protection	IP67 – Dust Tight, Waterproof
Illumination Voltage (Nominal)	5 ~ 28 VDC
Illumination Type, Color	LED, White/Blue
Features	Ceramic Actuator, Finger Guide, LINE Symbol
Detailed Description	Pushbutton Switch SPST-NC Capacitive, Illuminated Panel Mount, Front
Current Rating	100mA (AC/DC)
Color – Actuator/Cap	Clear (White Filter/Diffuser)
Circuit	SPST-NC
Actuator Type	Round, Button, Flush
