DF13-9P-1.25V(76)
| Part Number | DF13-9P-1.25V(76) |
|---|---|
| Description | CONNECTOR |
| Category | Connectors |
| Manufacturer | Hirose |
| In Stock | 15518 |
| Datasheet | Download |
Description
| Manufacturer | Hirose |
|---|---|
| Lead / RoHS Status | Lead free / RoHS Compliant |
| Voltage Rating | 150V |
| Termination | Solder |
| Style | Board to Cable/Wire |
| Shrouding | Shrouded – 3 Wall |
| Series | DF13 |
| Pitch – Mating | 0.049″ (1.25mm) |
| Packaging | Tube |
| Other Names | 536-0208-2-76 |
| Operating Temperature | -35°C ~ 85°C |
| Number of Rows | 1 |
| Number of Positions Loaded | All |
| Number of Positions | 9 |
| Mounting Type | Surface Mount |
| Material Flammability Rating | UL94 V-0 |
| Insulation Material | Polyamide (PA), Nylon |
| Insulation Height | 0.189″ (4.80mm) |
| Insulation Color | Beige |
| Features | Board Guide, Solder Retention |
| Fastening Type | Detent Lock |
| Detailed Description | Connector Header Surface Mount 9 position 0.049″ (1.25mm) |
| Current Rating | 1A |
| Contact Type | Male Pin |
| Contact Shape | Square |
| Contact Material | Brass |
| Contact Finish Thickness – Post | 8.00µin (0.203µm) |
| Finish Thickness – Mating | 8.00µin (0.203µm) |
| Contact Finish – Post | Gold |
| Contact Finish – Mating | Gold |
| Connector Type | Header |
