ES03MCKE
Description
| Manufacturer | C&K |
|---|---|
| Lead / RoHS Status | Contains lead / RoHS non-compliant |
| Voltage Rating – DC | 20V |
| Voltage Rating – AC | 20V |
| Termination Style | PC Pin |
| Switch Travel | 2.29mm |
| Switch Function | On-Off-On |
| Series | ES |
| Packaging | Tray |
| Other Names | *ES03MCKE CKN1247 |
| Operating Temperature | -30°C ~ 85°C |
| Mounting Type | Through Hole |
| Mechanical Life | 40,000 Cycles |
| Features | Epoxy Sealed Terminals, IP57 |
| Electrical Life | 40,000 Cycles |
| Detailed Description | Slide Switch SPDT Through Hole |
| Current Rating | 0.4VA (AC/DC) |
| Contact Timing | Not Specified |
| Contact Material | Phosphor Bronze |
| Contact Finish | Gold |
| Circuit | SPDT |
| Actuator Type | Standard |
| Actuator Material | Liquid Crystal Polymer (LCP) |
| Actuator Length | 3.07mm |
