MCA500-14IO1
| Part Number | MCA500-14IO1 |
|---|---|
| Description | SCR THRYRISTOR CA 1400V WC-500 |
| Category | Discrete Semiconductor Products |
| Manufacturer | IXYS Corporation |
| In Stock | 19761 |
| Datasheet | Download |
Description
| Manufacturer | IXYS Corporation |
|---|---|
| Lead / RoHS Status | Lead free / RoHS Compliant |
| Voltage – Off State | 1.4kV |
| Voltage – Gate Trigger (Vgt) | 3V |
| Structure | Common Anode – All SCRs |
| Packaging | Tray |
| Package / Case | WC-500 |
| Operating Temperature | -40°C ~ 125°C (TJ) |
| Number of SCRs, Diodes | 2 SCRs |
| Mounting Type | Chassis Mount |
| Moisture Sensitivity Level | 1 (Unlimited) |
| Detailed Description | SCR Module 1.4kV 1294A Common Anode – All SCRs Chassis Mount WC-500 |
| Current – On State (It (RMS)) (Max) | 1294A |
| Current – On State (It (AV)) (Max) | 545A |
| Current – Surge 50 60Hz Itsm | 16500A @ 50Hz |
| Current – Hold (Ih) (Max) | 1A |
| Current – Gate Trigger Igt | 300mA |
| Base Part Number | MC*500 |
