PHG.1B.302.CLLD42
| Part Number | PHG.1B.302.CLLD42 |
|---|---|
| Description | CONN RCPT FMALE 2POS SOLDER CUP |
| Category | Connectors |
| Manufacturer | LEMO |
| In Stock | 15247 |
| Datasheet | Download |
Description
| Manufacturer | LEMO |
|---|---|
| Lead / RoHS Status | Lead free / RoHS Compliant |
| Termination | Solder Cup |
| Shielding | Shielded |
| Shell Size – Insert | 302 |
| Shell Material | Brass |
| Shell Finish | Chrome |
| Series | 1B |
| Packaging | Bulk |
| Orientation | G |
| Operating Temperature | -55°C ~ 250°C |
| Number of Positions | 2 |
| Mounting Type | Free Hanging (In-Line) |
| Moisture Sensitivity Level | 1 (Unlimited) |
| Material Flammability Rating | UL94 V-0 |
| Insert Material | Polyetheretherketone (PEEK) |
| Ingress Protection | IP50 – Dust Protected |
| Features | Backshell |
| Fastening Type | Push-Pull |
| Detailed Description | 2 Position Circular Connector Receptacle, Female Sockets Solder Cup Gold |
| Current Rating | 15A |
| Contact Material | Bronze |
| Finish Thickness – Mating | 59.0µin (1.50µm) |
| Contact Finish – Mating | Gold |
| Connector Type | Receptacle, Female Sockets |
| Color | Silver |
| Cable Opening | 0.122″ ~ 0.165″ (3.10mm ~ 4.20mm) |
| Backshell Material, Plating | Brass, Chrome |
